Ka-Band Power Amplifier with Uni-Guide™

34 to 37 GHz, 50 dB Gain, +40 dBm Psat, 2.92 mm (F), WR-28 Waveguide
SBP-3433735038-KF28-E3-2 is a power amplifier with a typical small signal gain of 50 dB and a nominal P1dB of +38 dBm across the frequency range of 34 to 37 GHz. The DC power requirement for the amplifier is +28 VDC/5 A. The RF input is a 2.92 mm female connector, and the output is a WR-28 Uni-Guide™ waveguide. Other port configurations, such as male K connectors for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency34 GHz
Maximum Frequency37 GHz
Gain50 dB
P1dB+38 dBm
Psat+40 dBm
Input Return Loss9 dB
Output Return Loss9 dB
DC Voltage+28 VDC
DC Bias5000 mA
RF Input/Output2.92 mm (F) Connector/WR-28 Uni-Guide™ Waveguide
