Ka-Band Junction Isolator

34 to 36 GHz, 20 dB Isolation, WR-28 Waveguide
SKU:SNW-3433630320-28-I1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SNW-3433630320-28-I1 is a Ka band, waveguide junction isolator that covers the frequency range of 34 to 36 GHz. Compared with a Faraday isolator, the waveguide junction isolator offers a lower insertion loss of 0.3 dB nominal and a much shorter insertion length for system integration. As a tradeoff, the waveguide junction isolator only offers a typical isolation of 20 dB. The input and output ports are WR-28 waveguides with UG-599/U flanges.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $275.00
25 - 49 $247.50
50 - 99 $222.75

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency34 GHz
Maximum Frequency36 GHz
Insertion Loss0.3 dB
Isolation20 dB
VSWR1.4
Forward Power Handling3 W (CW)
Reverse Power Handling1 W (CW)
RF PortWR-28 Waveguide
Device TypeIsolator
