Q-Band Quadrature Mixer

33 to 50 GHz, DC to 2 GHz IF, +17 dBm LO Power, WR-22 Waveguide
SKU:SFQ-33350312-2222SF-N1-M
Availability:6 to 8 Weeks ARO
SFQ-33350312-2222SF-N1-M is a broadband quadrature mixer that covers the frequency range of 33 to 50 GHz. The typical conversion loss of the quadrature mixer is 12 dB with an LO driving power of +17 dBm. The typical LO to RF port isolation is 30 dB. Since the IF port of the quadrature mixer is DC coupled, the mixer can be used as a phase detector. In addition, the mixer can be readily configured into an image rejection mixer or single sideband modulator by adding an IF quadrature coupler. The mechanical configuration offers an inline structure with WR-22 Uni-Guide™ waveguides. Other port configurations, such as 2.4 mm connectors, are also available under different model number, SFQ-30350311-2222SF-N1-M.
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 2$3,450.00
3 - 4$3,277.50
5 +$3,113.63

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum RF Frequency33 GHz
Maximum RF Frequency50 GHz
Minimum LO Frequency33 GHz
Maximum LO Frequency50 GHz
Minimum IF FrequencyDC
Maximum IF Frequency2 GHz
LO Pumping Power+17 dBm
Conversion Loss12 dB
RF PortWR-22 Waveguide
