Q-Band Low Noise Amplifier with Uni-Guide™

33 to 50 GHz, 30 dB Gain, 4.0 dB Noise Figure, 2.4 mm (F), WR-22 Waveguide
SKU:SBL-3335033040-2F22-E1
Availability:Contact Us for Quote
SBL-3335033040-2F22-E1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 4.0 dB across the frequency range of 33 to 50 GHz. The DC power requirement for the amplifier is +8 VDC/160 mA. The mechanical configuration offers an inline structure with 2.4 mm (F) as input port and WR-22 Uni-Guide™ waveguide as output. Other port configurations, such as a right angle structure with WR-22 waveguides or 2.4 mm connectors, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,150.00
3 - 4 $2,992.50
5 - 9 $2,842.88

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency50 GHz
Gain30 dB
Noise Figure4.0 dB
P1dB+12 dBm
Input Return Loss6 dB
Output Return Loss8 dB
DC Bias+8 VDC/160 mA
RF Input/Output2.4 mm (F) Connector/WR-22 Uni-Guide™ Waveguide
