X4 Active Frequency Multiplier with Uni-Guide™

33 to 50 GHz, +20 dBm Output Power, In-line WR-22 Waveguide, Q-Band
SKU:SFA-224SF-E1
Availability:4 to 6 Weeks ARO
SFA-224SF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 8.25 to 12.50 GHz with a typical input power of +5 dBm and an output frequency of 33 to 50 GHz with a typical output power of +20 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The mechanical configuration is an inline structure with a SMA (F) connector as its input port and a WR-22 Uni-Guide™ waveguide as its output port. Other port configurations, such as a right angle structure with SMA connector as input port and WR-22 waveguide output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $4,400.00
3 - 4 $4,180.00
5 - 9 $3,971.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency33 GHz
Maximum Output Frequency50 GHz
Output Power+20 dBm
Minimum Input Frequency8.25 GHz
Maximum Input Frequency12.50 GHz
Input Power+5 dBm
DC Bias+8 VDC/600 mA
Output PortWR-22 Uni-Guide™ WG
Input PortSMA (F)
