X2 Active Frequency Multiplier with Uni-Guide™

33 to 50 GHz, +20 dBm Output Power, In-line WR-22 Waveguide, Q-Band
Availability:3 to 5 Days ARO
SFA-222KF-E1 is an active X2 frequency multiplier. The multiplier has an input frequency of 16.5 to 25.0 GHz with a typical input power of 0 dBm and an output frequency of 33 to 50 GHz with a typical output power of +20 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The mechanical configuration is an inline structure with a K (F) connector as its input port and a WR-22 Uni-Guide™ waveguide as its output port. Other port configurations, such as right angle structure with K connector as input port and WR-22 waveguide output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency33 GHz
Maximum Output Frequency50 GHz
Output Power+20 dBm
Minimum Input Frequency16.5 GHz
Maximum Input Frequency25 GHz
Input Power0 dBm
DC Bias+8 VDC/750 mA
Output PortWR-22 Uni-Guide™ WG
Input Port2.92 mm (F)
