Q-Band Low Noise Amplifier

33 to 50 GHz, 20 dB Gain, 5.0 dB Noise Figure, 2.4 mm (F)
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-3335031550-2F2F-S1 is a low noise amplifier with a typical small signal gain of 20 dB, a nominal noise figure of 5.0 dB and P1dB of +13 dBm across the frequency range of 33 to 50 GHz. The DC power requirement for the amplifier is +8 VDC/120 mA. The input and output port configurations are both female 2.4 mm connectors. Other port configurations, such as male 2.4 mm connectors and WR-22 waveguides for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $2,450.00
5 - 9 $2,205.00
10 - 24 $1,984.50

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency50 GHz
Gain20 dB
Noise Figure5.0 dB
P1dB+13 dBm
Input Return Loss10 dB
Output Return Loss15 dB
DC Bias+8 VDC/120 mA
RF Input/Output2.4 mm (F)
