Ka-Band Low Noise Amplifier with Uni-Guide™

33 to 37 GHz, 30 dB Gain, 3.0 dB Noise Figure, In-line WR-28 Waveguide
SKU:SBL-3333733030-2828-E1
Availability:Contact Us for Quote
SBL-3333733030-2828-E1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 3 dB across the frequency range of 33 to 37 GHz. The input and output port configurations are both WR-28 Uni-Guide™ waveguides. Other port configurations, such as K connectors, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency37 GHz
Gain30 dB
Noise Figure3.0 dB
P1dB+10 dBm
Input Return Loss10 dB
Output Return Loss15 dB
DC Bias+8 VDC/150 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide
