E-Band Lens Corrected Antenna

33 dBi Gain, 76.9 to 77.1 GHz, WR-12 Waveguide
SKU:SAK-AL773773-12-C2
Availability:Contact Us for Quote
SAK-AL773773-12-C2 is a E-band lens corrected antenna that operates from 76.9 GHz to 77.1 GHz. The antenna offers 33 dBi nominal gain and a typical half power beamwidth of 1.3 degrees on the E-plane and 10.4 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-12 waveguide with UG-387/U flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency76.9 GHz
Maximum Frequency77.1 GHz
Gain33 dBi
3 dB Beamwidth (E-plane, H-plane)1.3°, 10.4°
Return Loss14 dB
PolarizationLinear
Antenna PortWR-12 Waveguide
