Ka-Band Junction Isolator

33.6 to 36.4 GHz, 18 dB Isolation, WR-28 Waveguide, 3.1 mm Thru Holes
SKU:SNW-3433630518-28-I8-1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SNW-3433630518-28-I8-1 is a Ka band waveguide junction isolator that covers the frequency range of 33.6 to 36.4 GHz. Compared with a Faraday isolator, the waveguide junction isolator offers a lower insertion loss of 0.5 dB typical and a much shorter insertion length for system integration. As a tradeoff, the waveguide junction isolator only offers a typical isolation of 18 dB. The input and output ports are WR-28 waveguides with UG-599/U flanges and 3.1 mm thru holes.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 24 $275.00
25 - 49 $247.50
50 - 99 $222.75

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency33.6 GHz
Maximum Frequency36.4 GHz
Insertion Loss0.5 dB
Isolation18 dB
VSWR1.35
Forward Power Handling2 W (CW)
Reverse Power Handling0.5 W (CW)
RF PortWR-28 Waveguide
Device TypeIsolator
