Ka-Band Power Amplifier

SBP-3233734045-KF28-E1-R is a power amplifier with a typical power gain of 40 dB and nominal Psat of +46 dBm across the frequency range of 32 to 37 GHz. The power supply for the amplifier is 110 VAC to 220 VAC. The RF input is a 2.92 mm female connector and the output is a WR-28 waveguide. Other port configurations, such as male 2.92 mm connectors for either the input or output port, are also available under different model numbers.
Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
