Dielectric Resonator Oscillator

3 GHz, ±10 MHz Tuning Range, +13 dBm Output Power, SMA (F)
SKU:SOD-03302113-SF-C2
Availability:Contact Us for Quote
SOD-03302113-SF-C2 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 3.0 GHz and a mechanical tuning range of ±10 MHz. The oscillator delivers a nominal output power of +13 dBm with a low phase noise and harmonic emissions. The oscillator takes a +12 VDC/200 mA DC bias. The RF output is equipped with a female SMA connector.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency3.0 GHz
Output Power+13 dBm
Mechanical Tuning Range±10 MHz
Phase Noise-95 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-20 dBc
Bias+12 VDC/200 mA
RF PortSMA (F)
