Ka-Band Power Amplifier

26 to 40 GHz, 62 dB Gain, +47.5 dBm Psat, 2.92 mm (F), WR-28 Waveguide
SKU:SBP-2634036248-KF28-EP
Availability:Contact Us for Quote
SBP-2634036248-KF28-EP is a power amplifier with a typical small gain of 62 dB and a nominal Psat of +47.5 dBm across the frequency range of 26 to 40 GHz. The mechanical configurations is an inline structure with 2.92 mm (F) connector as its input port and WR-28 waveguide with UG-599/U Flange as output port. Other port configurations, such as K (M) connectors and WR-28 waveguides for either the input or output port, are also available under different model numbers.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26 GHz
Maximum Frequency40 GHz
Gain62 dB
Psat+47.5 dBm
Pin+10 dBm
Input Return Loss10 dB
Output Return Loss5 dB
DC Voltage+22 VDC
DC Bias18000 mA
RF Input/Output2.92 mm (F)/WR-28 Waveguide
ConfigurationStandard
