Dielectric Resonator Oscillator

26 GHz, ±150 MHz Tuning Range, +26 dBm Output Power, 2.92 mm (K) Female
SKU:SOD-26303226-KF-S1
Availability:Contact Us for Quote
SOD-26303226-KF-S1 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 26 GHz and a mechanical tuning range of ±150 MHz. The oscillator delivers a nominal output power of +26 dBm with a low phase noise and harmonic emissions. The oscillator takes a +8 VDC/600 mA DC bias. The RF output is equipped with a female 2.92 mm (K) connector.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency26 GHz
Output Power+26 dBm
Mechanical Tuning Range±150 MHz
Phase Noise-100 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-20 dBc
Bias+8 VDC/600 mA
RF Port2.92 mm (F)
