Ka-Band Low Noise Amplifier with Uni-Guide™

26.5 to 40 GHz, 30 dB Gain, 3.0 dB Noise Figure, In-line WR-28 Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-2634033030-2828-E1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 3 dB across the frequency range of 26.5 to 40 GHz. The DC power requirement for the amplifier is +8 VDC/150 mA. The RF connectors are WR-28 Uni-Guide™ waveguides. Other port configurations, such as K connectors for either the input or output port, are also available under different model numbers.
Login to View Pricing

Bulk Pricing

1 - 4$2,150.00
5 - 9$1,935.00
10 - 24$1,741.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain30 dB
Noise Figure3.0 dB
P1dB+10 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/150 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide
