X4 Active Frequency Multiplier with Uni-Guide™

26.5 to 40 GHz, +20 dBm Output Power, In-line WR-28 Waveguide, Ka-Band
SKU:SFA-284SF-E1
Availability:1 Week ARO
SFA-284SF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 6.63 to 10 GHz with a typical input power of +5 dBm and an output frequency of 26.5 to 40 GHz with a typical output power of +20 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$3,350.00
3 - 4$3,182.50
5 - 9$3,023.38

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Output Frequency26.5 GHz
Maximum Output Frequency40 GHz
Output Power+20 dBm
Minimum Input Frequency6.63 GHz
Maximum Input Frequency10 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortWR-28 Uni-Guide™ WG
Input PortSMA (F)
