Ka-Band Low Noise Amplifier with Uni-Guide™

26.5 to 40 GHz, 20 dB Gain, 3.0 dB Noise Figure, 2.92 mm (F), WR-28 Waveguide
SKU:SBL-2634032030-KF28-E1
Availability:1 Week ARO
SBL-2634032030-KF28-E1 is a low noise amplifier with a typical small signal gain of 20 dB and a nominal noise figure of 3 dB across the frequency range of 26.5 to 40 GHz. The DC power requirement for the amplifier is +8 VDC/70 mA. The input port configuration is female K connector and the output port is a WR-28 Uni-Guide™ waveguide. Other port configurations, such as male K connectors for either the input or output port, are also available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,750.00
5 - 9$1,575.00
10 - 24$1,417.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain20 dB
Noise Figure3.0 dB
P1dB+8 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/70 mA
RF Input/Output2.92 mm (F) Connector/WR-28 Uni-Guide™ Waveguide
