Ka-Band Low Noise Amplifier

26.5 to 40 GHz, 18 dB Gain, 4.0 dB Noise Figure, 2.92 mm (F)
SKU:SBL-2734031840-KFKF-E3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-2734031840-KFKF-E3 is a low noise amplifier with a typical small signal gain of 18 dB, a nominal P1dB of +11 dBm, and a noise figure of 4 dB across the frequency range of 26.5 to 40 GHz. The DC power requirement for the amplifier is +5 VDC/ 70 mA. The RF connectors are female K connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain18 dB
Noise Figure4.0 dB
P1dB+11 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+5 VDC/70 mA
RF Input/Output2.92 mm (F)
