Ka-Band Compact Fixed Attenuator

26.5 to 40 GHz, 10 dB, 2.0" Insertion Length, WR-28 Waveguide
SKU:STA-10-28-F1-C-2.0-V
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STA-10-28-F1-C-2.0-V is a compact fixed attenuator with an insertion length of 2.0”. The attenuator is used in millimeterwave systems and operates from 26.5 to 40 GHz. The attenuator has a fixed attenuation value of 10 dB at the center frequency, 33.25 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. The attenuator uses only low outgassing materials and adhesives in its construction to ensure that it is safe to use in thermal vacuum environments. The attenuator also includes vent holes to assist in the depressuration of the unit in vacuum environments. Other attenuation values are available under different model numbers as STA-XX-28-F1-C-2.0-V, where XX is the desired attenuation value.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,470.00
5 - 9 $1,323.00
10 - 24 $1,190.70

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Attenuation10 dB @ 33.25 GHz
Return Loss20 dB
Power Handling0.50 W (CW) (Max)
RF PortWR-28 Waveguide
Attenuator TypeFixed
