SMA Coaxial Bandpass Filter

25 to 26 GHz, 70 dB Rejection
SKU:SCF-26301370-SFSF-B3
Availability:6 to 8 Weeks ARO
SCF-26301370-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 25 to 26 GHz. The typical insertion loss of the bandpass filter is 3 dB and the passband ripple is ±0.5 dB. The rejection frequencies are 23.5 GHz or less and 27.5 GHz or higher. The typical rejection is 70 dB and the typical passband return loss of the filter is 11 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$900.00
10 - 24$810.00
25 +$729.00

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Passband Frequency25 GHz
Maximum Passband Frequency26 GHz
Low Side Rejection70 dB
High Side Rejection70 dB
Return Loss11 dB
Insertion Loss3 dB
Impedance50 Ohms
RF PortsSMA (F)
