WR-34 Waveguide Rectangular Horn Antenna

25 dBi Gain, 22 to 33 GHz
SKU:SAR-2507-34-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-2507-34-S2 is a WR-34 pyramidal horn antenna that operates from 22 to 33 GHz. The antenna offers 25 dBi nominal gain and a typical half power beamwidth of 7 degrees on the E-plane and 9 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-34 waveguide with UG-1530/U flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

QuantityPrice
1 - 9$820.00
10 - 24$738.00
25 +$664.20

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency22 GHz
Maximum Frequency33 GHz
Gain25 dBi
3 dB Beamwidth, E-Plane
3 dB Beamwidth, H-Plane
Return Loss23 dB
Antenna PortWR-34 Waveguide
