Ka-Band Receiver

24 to 42 GHz, DC to 12 GHz IF, +0 dBm LO Power
SKU:SSR-3331834012-28-S1
SSR-3331834012-28-S1 is an integrated receiver module. The Ka-Band receiver has a typical conversion gain of 12 dB with a typical Noise Figure of 4 dB in the frequency range of 24 to 42 GHz. The required LO power is 0 dBm between frequencies of 12 and 21 GHz. The RF Receive port is WR-28 Uni-Guide™ Waveguide with UG-599/U Flange while the LO port is female 2.92mm (K) connectors. Other port configurations, are also available under different model numbers such as SSR-3331834012-KF-S1.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency24 GHz
Maximum RF Frequency42 GHz
Noise Figure4 dB
Gain12 dB
LO Frequency12 GHz
LO Input Power0 dBm
Bias Voltage8 VDC
RF PortWR-28 Waveguide
