WR-28 Waveguide Standard Gain Horn Antenna

24 dBi Gain, Ka-Band
SKU:SAZ-2434432410-28-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAZ-2434432410-28-S1 is a Ka-band standard gain horn antenna that operates from 24 GHz to 44 GHz. The antenna offers 24 dBi nominal gain, a typical half power beamwidth of 9.4 degrees on the E-plane and 10.8 degrees on the H-plane at the center frequency, respectively. The antenna supports linear polarized waveforms. The input of this antenna is a WR-28 waveguide with UG-599/U flange. The standard gain horn is offered for antenna range calibration purpose mainly, but it can be also used for general purpose system set ups.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency24 GHz
Maximum Frequency44 GHz
Gain24 dBi
3 dB Beamwidth, E-Plane9.4°
3 dB Beamwidth, H-Plane10.8°
Return Loss20 dB
Antenna PortWR-28 Waveguide
