WR-15 Waveguide Standard Gain Horn Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR15GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-WR15PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAZ-2410-15-S1 is a V-band standard gain horn antenna that operates from 50 GHz to 75 GHz. The antenna offers 24 dBi nominal gain, a typical half power beamwidth of 9.5 degrees on the E-plane and 11 degrees on the H-plane at the center frequency, respectively. The antenna supports linear polarized waveforms. The input of this antenna is a WR-15 waveguide with UG-385/U flange. The standard gain horn is offered for antenna range calibration purpose mainly, but it can be also used for general purpose system set ups.
