K-Band Volume Production Varactor Tuned Gunn Oscillator, Limited Run

24.125 GHz, ±0.15 GHz Varactor Tuning Bandwidth, +7 dBm Output Power, WR-42 Waveguide
SKU:SOL-24307-42-GV
Availability:1 to 2 Weeks ARO
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should contact us for an alternative model. Read more about Limited Run Products here.

SOL-24307-42-GV is a volume-production ready, K Band Varactor tuned Gunn oscillator that utilizes high performance GaAs Gunn and Varactor diodes, optimized in the high Q cavity, to achieve excellent phase noise and power stability. The oscillator delivers +7 dBm output power at 24.125 GHz with an electrical tuning bandwidth of ±150 MHz. The center frequency of the oscillator can be mechanically trimmed by using the self-locking set screw provided. The oscillator takes +5 VDC/250 mA DC power.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $490.00
25 - 49 $441.00
50 - 99 $396.90

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency24.125 GHz
Output Power+7 dBm
Mechanical Tuning Range±50 MHz
Varactor Tuning Range±150 MHz
Phase Noise-95 dBc/Hz @ 100 KHz offset
Bias+5.0 VDC/250 mA
Varactor Tuning Voltage Range0 to +20 Volts
RF PortWR-42 Waveguide
