WR-42 Waveguide Highpass Filter

24.1 GHz and Higher Passband, 40 dB Rejection from DC to 23.1 GHz, K-Band
SKU:SWF-24323340-42-H1
Availability:4 to 6 Weeks ARO
SWF-24323340-42-H1 is a K band waveguide highpass filter with a passband frequency of 24.1 GHz and higher and a rejection frequency from DC to 23.1 GHz. The filter provides a nominal insertion loss of 0.5 across its passband and a typical rejection of 40 dB. Since the low end cutoff frequency can be changed by modifying the design, custom designs can be offered under different model numbers. For quantities above 10 pieces, please contact us or call (424) 757-0168.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$880.00
10 - 24$792.00
25 +$712.80

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Passband Frequency24.1 GHz
Passband Insertion Loss0.5 dB
Minimum Rejection FrequencyDC
Maximum Rejection Frequency23.1 GHz
Rejection40 dB
Waveguide PortWR-42 Waveguide
