X2 Active Frequency Multiplier with Uni-Guide™

22 to 44 GHz, +16 dBm Output Power, In-line WR-28 Waveguide, Ka-Band
SKU:SFA-223443216-28SF-E1
Availability:1 to 2 Weeks ARO
SFA-223443216-28SF-E1 is an active X2 frequency multiplier. The multiplier has an input frequency of 11 to 22 GHz with a typical input power of +5 dBm and an output frequency of 22 to 44 GHz with a typical output power of +16 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 2 $2,750.00
3 - 4 $2,612.50
5 - 9 $2,481.88

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Output Frequency22 GHz
Maximum Output Frequency44 GHz
Output Power+16 dBm
Minimum Input Frequency11 GHz
Maximum Input Frequency22 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortWR-28 Uni-Guide™ WG
Input PortSMA (F)
