K-Band Lens Corrected Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-06D.
A 2D pattern measurement test is offered under service number FTA-0400PATT-06D.

CLICK HERE to read more about our antenna measurement capabilities.

SAL-2232732212-368-S1 is a K-band lens corrected antenna that operates from 22 to 27 GHz. At center frequency, the antenna delivers 22 dBi nominal gain and 12 degrees typical half power beamwidth. The antenna employs a low loss lens to offer excellent aperture efficiency and low sidelobe levels. The lens corrected antenna is equipped with a 0.368" diameter circular waveguide and UG-595/U flange as its input port. It supports both linear and circular polarized waveforms.
