Positive Amplitude Detector

210 to 230 GHz, 800 mV/mW Sensitivity, WR-04 Waveguide
SKU:SFD-214234-04SF-P1-M
Availability:4 to 5 Weeks ARO
SFD-214234-04SF-P1-M is a WR-04 amplitude detector that can be used in the frequency range of 210 to 230 GHz. The detector is zero biased and intended for small signal detection purposes. The detector exhibits high sensitivity characteristics across the full waveguide operating bandwidth. The detector is designed to have a 10 MHz video bandwidth and a 1 MΩ video output impedance.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency210 GHz
Maximum Frequency230 GHz
Sensitivity800 mV/mW
Sensitivity Flatness
RF Input Power-20 dBm
Video Bandwidth10 MHz
Output Voltage PolarityPositive
RF PortWR-04 Waveguide
DC PortSMA (F)
