Ka-Band Power Amplifier

20 to 44 GHz, 35 dB Gain, +30 dBm P1dB, 2.4 mm (F)
SKU:SBP-2034433530-2F2F-S1-HR
Availability:Contact Us for Quote
SBP-2034433530-2F2F-S1-HR is a power amplifier with a typical small signal gain of 35 dB and a nominal P1dB of +30 dBm across the frequency range of 20 to 44 GHz. The DC power requirement for the amplifier is +8 VDC/4.0 A. The RF connectors are 2.4 mm female connectors. Other port configurations, such as K connectors and 1.85 mm connectors for either the input or output port, are also available under different model numbers.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency20 GHz
Maximum Frequency44 GHz
Gain35 dB
P1dB+30 dBm
Psat+32 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Voltage+8 VDC
DC Bias4000 mA
RF Input/Output2.4 mm (F)
ConfigurationHeatsink Included
