Broadband Single Sideband Modulator

20 to 42 GHz, 15 dB Conversion Loss, 18 dB Image Rejection
SKU:SFM-20342315-KFKFSF-N1-M
SFM-20342315-KFKFSF-N1-M is a 20 to 42 GHz Band single side band modulator that covers the frequency range of 20 to 42 GHz. The typical conversion loss of the modulator is 15 dB with the quadrature IF driving signals of ±10 Vp-p/2 mA for both I and Q ports. The typical input/output isolation and image rejection is 18 dB, respectively. In addition, the modulator can be readily used as an I/Q mixer or image rejection mixer by using one of the RF as LO port and/or adding the IF hybrid coupler.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,700.00
5 - 9 $1,530.00
10 - 24 $1,377.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Output RF Frequency Minimum20 GHz
Output RF Frequency Maximum42 GHz
IF Frequency MinimumDC
IF Frequency Maximum5 GHz
Conversion Loss15 dB
Image Rejection18 dB
