Ka-Band Conical Horn Antenna

20 dBi Gain, 26 to 33 GHz, 0.315" Diameter Circular Waveguide
SKU:SAC-2012-315-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAC-2012-315-S2 is a Ka-band conical horn antenna that operates from 26 to 33 GHz. The antenna offers 20 dBi nominal gain and a typical half power beamwidth of 16 degrees on the Eplane and 20 degrees on the H-plane. The horn also offers typical sidelobes of -20 dB on the Eplane and -28 dB on the H-plane. The conical horn can support linear and circular polarization. The antenna port is a 0.315" diameter circular waveguide with UG-599/U-M flange.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 24$490.00
25 - 49$441.00
50 - 99$396.90

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency26 GHz
Maximum Frequency33 GHz
Gain20 dBi
3 dB Beamwidth, E-Plane16°
3 dB Beamwidth, H-Plane20°
Return Loss23 dB
PolarizationLinear and Circular
Antenna Port0.315" Dia Circular WG
