4-Way Coaxial Power Splitter

2 to 40 GHz, 2.92 mm (F)
SKU:SCS-0234033015-KFKF-42
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCS-0234033015-KFKF-42 is a coaxial 4-way power splitter with a typical insertion loss of 3 dB at each output port and a typical isolation of 15 dB across the frequency range of 2 to 40 GHz. The power splitter has a nominal power handling of 20 W (CW) and a typical amplitude unbalance of ±0.8 dB. The return loss for all ports is 9 dB typical. The RF connectors of the power splitter are female 2.92 mm (K) connectors.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,500.00
5 - 9 $1,350.00
10 - 24 $1,215.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency2 GHz
Maximum Frequency40 GHz
Ways4
Insertion Loss3.0 dB
Port Isolation15 dB
Return Loss9 dB
Impedance50 Ohms
RF ConnectorsK (F)
