16-Way Coaxial Power Splitter

2 to 18 GHz, SMA (F)
SKU:SCS-0231835015-SFSF-162
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCS-0231835015-SFSF-162 is a coaxial 16-way power splitter with a typical insertion loss of 5 dB at each output port and a typical isolation of 15 dB across the frequency range of 2 to 18 GHz. The power splitter has a nominal power handling of 30 W (CW) and a typical amplitude unbalance of ±1.2 dB. The return loss for all ports is 9 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $2,450.00
5 - 9 $2,205.00
10 - 24 $1,984.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency2 GHz
Maximum Frequency18 GHz
Ways16
Insertion Loss5 dB
Port Isolation15 dB
Return Loss9 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
