SMA (F) Coaxial Power Limiter

2 to 18 GHz, +37 dBm Maximum Limiting Power, +20 dBm Leakage Power, 2 dB Insertion Loss
SKL-2021832037-SFSF-D2 is an electrical limiter that utilizes a high-performance GaAs Schottky diode MMIC chip to offer high performance power-limiting function. The limiter can handle RF power up to +37 dBm (CW) with a +20 dBm typical leakage power to protect power sensitive components, such as mixers, low noise amplifiers, switches etc. The limiter supports wide band operation from 2 to 18 GHz and offers a typical insertion loss of 2 dB. The RF connectors are female SMA connectors. Other port configurations, such as 2.92 mm connectors are readily available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency2 GHz
Maximum Frequency18 GHz
Insertion Loss2 dB
Return Loss12 dB
Leakage Power+20 dBm
Maximum Limiting Power+37 dBm
Input PortSMA Female
Output PortSMA Female
