W-Band Omnidirectional Antenna

2 dBi Gain, 75 to 110 GHz, WR-10 Waveguide
SKU:SAO-7531140230-10-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR10GAIN-ODA.
A 2D pattern measurement test is offered under service number FTA-WR10PATT-ODA.

CLICK HERE to read more about our antenna measurement capabilities.

SAO-7531140230-10-S1 is a W-band omnidirectional antenna that operates between 75 and 110 GHz. This vertically polarized antenna offers a 360-degree azimuth coverage with typical 2.0 dBi gain and ±0.5 dB gain flatness. The antenna features a half power typical beamwidth of 30 degrees in the vertical direction.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Gain2 dBi
Azimuth360°
3 dB Beamwidth, Vertical30°
Return Loss8 dB
InputWR-10 Waveguide
