E-Band Omnidirectional Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR12GAIN-ODA.
A 2D pattern measurement test is offered under service number FTA-WR12PATT-ODA.

CLICK HERE to read more about our antenna measurement capabilities.

SAO-6039030230-12-S1 is a WR-12 omnidirectional antenna that operates between 60 and 90 GHz. This vertically polarized antenna offers 360 degrees azimuth coverage with ±3 dB angular gain flatness. The antenna features a half power beamwidth of 30 degrees in the vertical direction and typical 2 dBi gain across the entire frequency range.
