Coaxial DC Block, Limited Run

2.92 mm, 5 MHz to 40 GHz
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SCB-050-KFKM-U2 as an alternative solution. Read more about Limited Run Products here.

SCB-050-KFKM-U7 is a coaxial DC block that prevents the flow of DC current in the frequency range of 5 MHz to 40 GHz. The DC block has a typical insertion loss of 0.4 dB, a nominal return loss of 18 dB, and a characteristic impedance of 50 ohms, respectively. It is manufactured with 2.92 mm male and female connectors for convenient circuit insertion. The breakdown voltage is +50 Volts.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency5 MHz
Maximum Frequency40 GHz
Return Loss18 dB
Impedance50 Ohms
Insertion Loss0.4 dB
Connector 12.92 mm Female
Connector 22.92 mm Male
