4-Way Coaxial Power Splitter

SCS-1835032215-2F2F-42 is a coaxial 4-way power splitter with a typical insertion loss of 2.2 dB at each output port and a typical isolation of 15 dB across the frequency range of 18 to 50 GHz. The power splitter has a forward power handling of 30 W (CW) and a typical amplitude unbalance of ±0.6 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female 2.4 mm connectors.
