Broadband Amplifier

18 to 45 GHz, 30 dB Gain, +22 dBm P1dB, 6.0 dB Noise Figure, 2.4 mm (F)
SKU:SBB-1834533022-2F2F-S1
Availability:3 to 5 Days ARO
SBB-1834533022-2F2F-S1 is a broadband amplifier with a typical small signal gain of 30 dB, a typical P-1dB of 22 dBm and a nominal noise figure of 6.0 dB across the frequency range of 18 to 45 GHz. The DC power requirement for the amplifier is +8 VDC/800 mA. The RF connectors are 2.4 mm female connectors for input and output. Other port configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency45 GHz
Gain30 dB
P1dB+22 dBm
Psat+23 dBm
Input Return Loss9 dB
Output Return Loss9 dB
DC Bias+8 VDC/800 mA
RF Input/Output2.4 mm (F)
