Broadband Amplifier

18 to 42 GHz, 28 dB Gain, +14 dBm P1dB, 4.0 dB Noise Figure, 2.92 mm (F)
SKU:SBB-1834232815-KFKF-E3
Availability:IN STOCKPlease contact us if you need more units than what is available online.

SBB-1834232815-KFKF-E3 is a broadband amplifier with a typical small signal gain of 28 dB, a nominal P1dB of +14 dBm, and a noise figure of 4.0 dB across the frequency range of 18 to 42 GHz. The DC power requirement for the amplifier is +5 VDC/240 mA. The RF connectors are female K connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.

ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency42 GHz
Gain28 dB
P1dB+14 dBm
Psat+16 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+5 VDC/240 mA
RF Input/OutputK (F)
