Broadband Absorptive SPDT PIN Diode Switch

18 to 40 GHz, 60 dB Isolation, 2.92 mm (F)
SKU:SKD-1834034560-KFKF-A3
Availability:3 Days ARO
SKD-1834034560-KFKF-A3 is an absorptive PIN diode based, single pole, double throw (SPDT) switch with a TTL driver that operates between 18 and 40 GHz. This model offers a typical insertion loss of 4.5 dB and 60 dB port-to-port isolation with a typical switching speed of 100 nanoseconds. The switch has female K connectors for all RF ports and solder pins for DC bias and TTL control.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$2,450.00
5 - 9$2,205.00
10 - 24$1,984.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency40 GHz
Insertion Loss4.5 dB
Isolation60 dB
Power Handling-
Bias±5 VDC/ 100/50 mA
Switching Speed100 ns
Switch TypeAbsorptive
RF Port2.92 mm (F)
