Broadband Low Noise Amplifier

18 to 40 GHz, 40 dB Gain, 3.0 dB Noise Figure, 2.92 mm (F)
SKU:SBL-1834034030-KFKF-S1
Availability:1 Week ARO
SBL-1834034030-KFKF-S1 is a low noise amplifier with a typical small signal gain of 40 dB and a nominal noise figure of 3 dB across the frequency range of 18 to 40 GHz. The DC power requirement for the amplifier is +8 VDC/200 mA. The input and output port configurations are both female K connectors. Other port configurations are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$2,850.00
3 - 4$2,707.50
5 - 9$2,572.13

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency40 GHz
Gain40 dB
Noise Figure3.0 dB
P1dB+10 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/200 mA
RF Input/Output2.92 mm (F)
