Broadband High Dynamic Range Electrical Attenuator

18 to 40 GHz, 37 dB Attenuation, 2.92 mm (F) RF Ports, SMA (F) Bias Port
Availability:1 Week ARO
SKA-1834033537-KFKF-A1-M is MMIC based electrical attenuator. The attenuator exhibits 3.5 dB typical insertion loss and 0 to 37 dB nominal attenuation range across the frequency range of 18 to 40 GHz while applying 0 to -3 VDC control voltage. While the control voltage of the standard model is 0 to -3 VDC, the maximum damage control voltage is - 5 VDC. The RF input and output ports are K(F) connectors, and the control port is with SMA(F) connector.
Login to View Pricing

Bulk Pricing

1 - 4$1,950.00
5 - 9$1,755.00
10 - 24$1,579.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency40 GHz
Insertion Loss3.5 dB
Attenuation37 dB
Damage RF Power Level+30 dBm
Control Bias0 to -3 VDC
Control Speed-
RF Port2.92 mm (F)
