K-Band Balanced Upconverter

18 to 26.5 GHz, DC to 8.5 GHz IF, +13 dBm LO Power, WR-42 Waveguide
SKU:SFU-42-N1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFU-42-N1 is a K Band balanced up-converter that utilizes high performance GaAs Schottky beam-lead diodes and a balanced circuit configuration to offer superior RF performance. The up-converter supports the full waveguide band operation for both LO and RF frequencies from 18 to 26.5 GHz with an IF output from DC to 8.5 GHz. The mixer offers a conversion loss of 6.0 dB typical and a high RF to LO port isolation of 30 dB.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency18 GHz
Maximum RF Frequency26.5 GHz
Minimum LO Frequency18 GHz
Maximum LO Frequency26.5 GHz
Minimum IF FrequencyDC
Maximum IF Frequency8.5 GHz
LO Pumping Power+13 dBm
Conversion Loss6 dB
RF PortWR-42 Waveguide
