K-Band Low Noise Amplifier

18 to 26.5 GHz, 50 dB Gain, 2.5 dB Noise Figure, 2.92 mm (F)
SKU:SBL-1832735025-KFKF-S1

SBL-1832735025-KFKF-S1 is a low noise amplifier with a typical small signal gain of 50 dB and a nominal noise figure of 2.5 dB across the frequency range of 18 to 26.5 GHz. The DC power requirement for the amplifier is +8/150 mA. The RF connectors are female K connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.

ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Gain50 dB
Noise Figure2.5 dB
P1dB+15 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/150 mA
RF Input/Output2.92 mm (F)
