K-Band Fixed Attenuator

18 to 26.5 GHz, 4 dB, 35 Watt Power Handling, WR-42 Waveguide, Compatible Choke Flange
SKU:STA-04-42-F1-H-2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STA-04-42-F1-H-2 is a 35 watt fixed attenuator that is used in millimeterwave systems and operates from 18.0 to 26.5 GHz. The attenuator has a nominal fixed attenuation value of 4 dB across the entire K band. The attenuator is uniquely designed and fabricated for full waveguide band applications and displays a flat frequency response across the full bandwidth. Various attenuation values are available under different model numbers. This item has limited stock. Please contact us if you require more units than what is available online.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,100.00
5 - 9 $990.00
10 - 24 $891.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Attenuation4 dB
Return Loss14 dB
Power Handling35 W
RF PortWR-42 Waveguide with Compatible Choke Flange
Attenuator TypeFixed
