K-Band Low Noise Amplifier

18 to 26.5 GHz, 30 dB Gain, 2.5 dB Noise Figure, 2.92 mm (F)
SKU:SBL-1832733025-KFKF-S1
Availability:3 Days ARO
SBL-1832733025-KFKF-S1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 2.5 dB across the frequency range of 18 to 26.5 GHz. The DC power requirement for the amplifier is +8 VDC/200 mA. The RF connectors are female K connectors. Other port configurations, such as male K connectors and WR-42 waveguides for either the input or output port, are also available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,950.00
5 - 9$1,755.00
10 +$1,579.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Gain30 dB
Noise Figure2.5 dB
P1dB+10 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/200 mA
RF Input/Output2.92 mm (F)
