Ka-Band Omnidirectional Antenna

18 dBi Gain, 26.5 to 40 GHz, 2.92 mm (F), Right Angle
SKU:SAO-2734031845-KF-R1-BL
Availability:1 to 2 Weeks ARO
SAO-2734031845-KF-R1-BL is a full band, Ka band Omnidirectional Receiving Antenna equipped with a Low Noise Amplifier. It covers the frequency range of 26.5 to 40 GHz. This vertically polarized antenna offers 360˚ azimuth coverage with 18 dBi typical gain, of which 3 dBi is from the Antenna and 15 dBi is from the integrated LNA. The antenna features a half power beamwidth of 45 degrees in its vertical direction. The power supply of the LNA can be provided via the USB Type-C port with Locking Screw for supply with a 5V battery pack. The LNA incorporates a DC regulator. The RF port of the antenna is equipped with a 2.92 mm female connector. The Amplified Antenna is built to resist indirect sprays of water.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain18 dBi
Azimuth360°
3 dB Beamwidth, Vertical45°
Return Loss10 dB
InputRight Angle 2.92 mm (F)
