WR-34 Waveguide Rectangular Horn Antenna

17 dBi Gain, 22 to 33 GHz
SKU:SAR-1725-34-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-1725-34-S2 is a WR-34 pyramidal horn antenna that operates from 22 to 33 GHz. The antenna offers 17 dBi nominal gain and a typical half power beamwidth of 26 degrees on the E-plane and 24 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-34 waveguide with UG-1530/U flange.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 9 $720.00
10 - 24 $648.00
25 - 49 $583.20

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency22 GHz
Maximum Frequency33 GHz
Gain17 dBi
3 dB Beamwidth, E-Plane26°
3 dB Beamwidth, H-Plane24°
Return Loss23 dB
Antenna PortWR-34 Waveguide
